Woven Ground Cover - High Flow
High Flow Woven Ground Cover Geotextile is a heavy-duty, high-flow, highly permeable fabric that increases stability and provides erosion control.
The woven ground cover fabrics prevent weed growth and allow air to circulate. This way the soil is not soured and roots are protected from the spread of fungus and bacteria. It has high flow rates for areas that need rapid water movement from the growing material.
Features
• Prevent weed growth.
• Prevent top soil erosion.
• Permeable to air and water.
• Provide beauty to the landscape
• Superior damage resistance
• Withstands tough construction loading
• Resistant to ultraviolet degradation
• Resistant to biological clogging
• Easily installed
• Reduces Maintenance Costs
• High Tensile Modulus & Low Elongation
Technical Data
Property | Test Method | Min. Average Roll Value |
Grab Tensile Strength | ASTM-D 4632 | 110 lbs |
Grab Elongation | ASTM-D 4632 | 15% |
Puncture | ASTM-D 4833 | 40 lbs |
CBR Puncture Strength | ASTM-D 6241 | 250 lbs |
Trapezoidal Tear | ASTM-D 4533 | 45 lbs |
Mullen Burst | ASTM-D 3786 | 125 psi |
UV Resistance @ 500 hours | ASTM-G 154 | 70% |
Apparent Opening Size AOS | ASTM-D 4751 | 40 sieve |
Permittivity | ASTM-D 4491 | 0.05sec-1 |
Flow Rate | ASTM-D 4491 | 4 gpm/ft2 |
Applications
• Soil Reinforcement
• Sub-base reinforcement
• Foundation support
• Separation
• Filtration
• MSE Walls & Slope Reinforcement
• Landfill & Lagoon Closures
• Embankment Stabilization
